Our Products
We are developers, manufacturers and suppliers of premium quality Electro-Magnetic Interference (EMI) Shielding products
With over 35 years experience in this market, we work with our Customers to ultimately offer a solution to your Shielding problem
Beryllium Copper
Copper is the most reliable metal to use in EMI Shielding because it is highly effective in attenuating magnetic and electrical waves.
The TBAPS's range of Beryllum Copper shielding gaskets provide high grade Electro Magnetic Interference protection, whilst providing superior mechanical spring characteristics for strength and fatigue resistance, plus excellent conductivity. They are ideally suited for applications where a high level of repeat access is required.
Our range offers the most complete line of standard BeCu shielding strips in the industry. Uncompressed heights of standard finger stock range from 0.76mm to 11.2mm, which will occupy gaps as low as 0.25mm. A line of standard connector gaskets are also available.
We are also able to supply Custom or semi-standard shielding for special applications, such as board level shielding and connector gaskets.
TBAPS range offer:
- Excellent spring qualities
- Longevity
- Low closing force
- Numerous plating options
- Conforms to large gap unevenness
- Attenuation exceeding 100db for most styles
and
- No-Snag series, eliminates finger damage and snagging
- Soft No-Snag series, low compression forces and self cleaning
- Symmetrical Series, Bi-directional sliding contact
- Panel Gasket series, can be compressed to stock thickness
- Four Installation Options, design flexibility
- Controlled Contact Resistance, consistent attenuation over time
- Range of Shapes and Sizes, custom fit at standard cost
Installation Options:
- Clip On
- Stick On
- Snap On
- OMNI
- Special
- Plastic Rivets
Available in:
- Roll Form
- Strips
- Cropped Fingers
- Contact Rings
- D Connectors
- Board Level Shields
Fabric over Foam
Fabric over Foam EMI Gaskets, are manufactured by forming a metallised fabric (conductive) over a foam core . The foam core is usually manufactured from urethane which gives very low compression, and offers excellent EMI shielding properties. This type of EMI Shielding gasket has very good wear properties, is resistant to abrasion (due to the metallised outer fabric), is very lightweight and cuts smoothly, for ease of installation.
Used for a variety of applications, where grounding and low compression are a requirement, such as indoor electronic housings, cabinet doors, grounding contacts etc.
Various Profiles are available and include:
- Flat
- D shape
- Square
- V Section
- J Section
- P Shape
- Round
- DD shape
- Knife Edge
The finishes include Nickel and Gold Plate
Shielding Fabrics
TBAPS produce and supply Fabrics in both woven and non woven types, for EMI Shielding purposes. these fabrics are suitable, not just for Industrial and Personal use, but are also suitable for use in Military applications.
Finishes include Nickel and Copper
These fabrics can also be coated, to provide good thermal properties alongside the Shielding.
Shielding fabrics are used in a variety of applications such as:-

- Mobile EMI Shielding Tents
- ID Protection
- Clothing
- Room and Window Shielding
- Architectural Shielding
EMI Cushions
These LCD foam Cushions are a highly conductive barrier.
They provide ESD Shielding so will dissipate an electrical charge safely. They also act as an EMI Shield, therefore protecting products/circuits from harmful electro-magnetic radiation or signals, during manufacture, assembly or repair.
Available in a variety of fabrics, finishes and thicknesses.
Designed for supporting LCD's in monitors, mobile phones, sat nav's etc.
Loaded Rubbers
Loaded Rubber Gaskets provide good environmental and EMI sealing and offer low contact resistance.
A combination of nano technology additives and intimate contact, provides lower contact resistance and superior environmental sealing.
The TBAPS form in place RTV or MS silicone gaskets offer excellent environmental and EMC sealing.
Suitable for use with TBAPS EMI Shielding Paints.
Types supplied are:-
- Moulded
- Extruded
- Printed Form in Place
- Die Cut
- Silicone and Fluorosilicone elastomers
Additives:-
- Carbon
- CNT/Graphene
- Nickel
- Graphite
- Copper
- Silver Glass
- Silver Aluminium
- Silver
- Silver additives
Oriented wire in solid or sponge silicone
EMI Vents
EMI Shielding Vents and Windows are manufactured in standard configurations, but we are able to customise to your own configurations., if required.
The benefits include EMI Shielding with no degradation on fan output, and allows ventilation without compromising the shielding integrity of the enclosure.

Ideal for use where maximum airflow is required, whilst maintaining EMC compliance.
Enclosure options include:-
- Twin Seal
- Mesh Gaskets
- BeCu Strip
- Fabric over Foam
We can offer ITO coated windows and mesh laminated windows
Suitable for use in:
- - Electronic enclosures
- - Fan Housings
- - EMC Racks
EMI Filters
EMI or Electo-Magnetic Interference, is defined as unwanted electrical signals and can be in the form of conducted or radiated emissions.
Most electronics contain an EMI Filter, either as a separate device, or embedded in circuit boards. Its function is to reduce high frequency electronic noise that may cause interference with other devices.
TBAPS offer:
- Single and Three phase filters
- Power surge protection
- 0.5A to 2500A
- 110v to 690v
TBAPT EMI Filters can be used with:
- BeCu
- Contact Rings
- D Connectors
EMI Shielding Tapes
EMI Shielding Tapes are a quick and easy fix for static grounding and EMI/RFI shielding for various components and applications. They offer superior abrasion characteristics and are corrosion resistant.
The tapes are available in:
- Metal foil and conductive fabric tapes
- With Conductive or Standard adhesive
- Various widths
- High Temperature masking versions
Some common applications are:
Shielding of doors, panels and seams in electrical enclosures
Shielding of seams in faraday cages or shielding rooms/labs
Shielding on or around Electrical Components and cables
Shielding around plastic housings and keyboards
Knitted Gaskets
Knitted gaskets offer high performance in EMI and Environmental sealing.
The TBAPS knitted gaskets are manufactured using Monel wire as the mesh, over either a Neoprene sponge core or Silicone tube core.
These gaskets offer high wear, and are corrosion and abrasive resistant.
Usual applications are:
- Door Sealing, for example communication cabinets
- Enclosure panels
- Conductive window and vent mounting
Thermally Conductive Interface
Heat and electronics do not mix, and therefore a Thermally Conductive Interface is required., especially when the surface is not entirely flat and thus creates an air gap. The interface is usually supplied as a pre-formed piece of solid material, which is placed on the underside of the heatsink to aid the conduction of heat away from the component or chip.
Thermal Interface Pads improve the thermal connection with heatsinks.
Projects
Some projects for which TBAPS have developed a solution
